Engraved Metal Nameplates
Showing all 6 results
Engraving cuts a mark into the metal itself, so it cannot peel or wear off the way printed ink can. Himgo uses laser engraving and chemical etching across stainless, aluminum, and brass for buyers who need marks that outlast the product.
- Laser engraving or chemical etching
- Works on stainless, aluminum, brass, or copper
- Optional recessed fill for contrast
- MOQ 100–500 pcs by complexity
- Sample lead time usually 5–7 days
Materials & finishes
| Option | Choices |
|---|---|
| Material | 304/316 stainless, aluminum 5052/6061, brass, or copper |
| Thickness | 0.3–3 mm |
| Size | 80x40mm, 100x60mm, 120x80mm, 150x100mm, or custom to your drawing |
| Finish | brushed, matte, mirror, or plated as a base before marking |
| Marking/Process | laser engraving (fine detail) or chemical etching (recessed, fillable) |
| Mounting | 3M adhesive, drilled holes, rivets, or screws |
Laser engraving keeps fine text sharp on small tags; chemical etching leaves a deeper recess that takes a paint fill for contrast on a plant floor.
Typical buyers & uses
- Tool and die shops — marking part numbers that survive years of handling in a machine shop.
- Medical device makers — a permanent serial that cannot be sanded off during resterilization.
- Outdoor gear and firearms brands — engraving serials for compliance tracing.
- Sign shops — raised or recessed relief lettering for a tactile nameplate.
Size & price reference
| Example spec | Ref US$/pc |
|---|---|
| 80x40mm laser engraved aluminum tag | $0.18–0.22 |
| 100x60mm chemically etched stainless, paint filled | $0.30–0.36 |
| 150x100mm deep engraved brass, plated finish | $0.46–0.53 |
Indicative only. Final price depends on engraving depth, fill, and quantity.
Ordering
- MOQ usually 100–500 pcs, by complexity of the engraving.
- Lead time: sample usually 5–7 days; bulk 12–30 days by quantity.
- Send vector artwork and specify engraving depth or fill preference.
- Samples are approved before the production run starts — see how we work.
FAQ
What is the difference between laser engraving and chemical etching?
Laser engraving burns fine detail directly into the surface. Chemical etching removes metal in a bath to leave a deeper, fillable recess.
Can engraved text be filled with paint for better contrast?
Yes, recessed etching accepts a paint fill; laser engraving usually reads well without one.
How deep can you engrave thin metal without weakening the plate?
On 0.3–1 mm stock we keep engraving shallow; thicker plates from 1.5 mm up allow a deeper cut.
Does laser engraving remove the anodized layer on aluminum?
Yes, the laser burns through the anodized coating, exposing bare aluminum for contrast.
Can each plate in a production run carry a different engraved serial number?
Yes, send your serial list or sequence and we engrave each plate individually.
