Custom Aluminum Nameplates
Showing all 6 results
Aluminum keeps a nameplate light and resists corrosion without the cost of stainless, and anodizing opens up color options etching alone can’t match. Himgo cuts these from 5052 or 6061 sheet for brands and manufacturers who want a distinct look without added weight.
- Aluminum 5052 or 6061, 0.3–3 mm
- Anodized, brushed, mirror, or painted finish
- Sizes 80x40mm to 150x100mm
- MOQ 100–500 pcs by complexity
- Sample lead time usually 5–7 days
Materials & finishes
| Option | Choices |
|---|---|
| Material | aluminum 5052 (formable) or 6061 (stiffer), or your drawing |
| Thickness | 0.3–3 mm |
| Size | 80x40mm, 100x60mm, 120x80mm, 150x100mm, or custom to your drawing |
| Finish | anodized (color range), brushed, mirror, or painted |
| Marking/Process | laser engraving, chemical etching, screen printing, or stamping |
| Mounting | 3M adhesive, drilled holes, rivets, or screws |
5052 bends around curved housings without cracking; 6061 stays flatter under handling on panels bolted to a rigid frame.
Typical buyers & uses
- Electronics makers — nameplates that do not add bulk to a compact enclosure.
- Consumer product brands — matching an anodized color to the product’s own finish.
- Trailer and transport builders — lightweight ID tags applied across many units.
- Appliance manufacturers — choosing aluminum over stainless for indoor units.
Size & price reference
| Example spec | Ref US$/pc |
|---|---|
| 80x40mm brushed aluminum, printed logo | $0.17–0.21 |
| 100x60mm anodized aluminum, laser engraved text | $0.26–0.32 |
| 150x100mm aluminum, etched with color fill | $0.42–0.50 |
Indicative only. Final price depends on anodizing color, marking method, and quantity.
Ordering
- MOQ usually 100–500 pcs, by complexity of the finish.
- Lead time: sample usually 5–7 days; bulk 12–30 days by quantity.
- Send your artwork, target anodized color if any, and mounting preference.
- Samples are approved before the production run starts — see how we work.
FAQ
Which aluminum grade holds up well for a curved panel, 5052 or 6061?
5052 forms around curves without cracking; 6061 suits flat panels that need more rigidity.
Can anodized aluminum be matched to a specific color reference?
Yes, send a Pantone or RAL reference and we match the anodizing dye as closely as the process allows.
Does anodizing change how laser engraving looks on the surface?
Yes, engraving through an anodized layer exposes the bare aluminum underneath, giving strong contrast against the color.
Is aluminum a good choice for nameplates near salt water?
Aluminum resists general corrosion, but 316 stainless holds up better under constant salt spray. Salt-spray testing is available on request.
Can aluminum nameplates be trimmed to an irregular shape?
Yes, send your outline as a vector file and we cut to that profile.
