Engraved Serial Number Nameplates
Nameplates engraved with serial numbers, batch codes, or QR data from your sequence file, each mark held consistent across the full run.
Description
Tracking equipment across a production run means every plate needs its own number. Himgo engraves serial numbers, batch codes, or QR data plate by plate from a single sequence file you supply. Each mark stays consistent in size and depth. A scanner or inspector reads plate one and plate one thousand the same way.
Build options
Aluminum and stainless steel both hold serial data well under laser engraving, at a mark depth around 0.01-0.05mm. Anodized aluminum gives strong contrast for barcodes; brushed stainless suits environments with heavier handling. Brass is available where a plate also carries a brand mark alongside the serial field.
Common dimensions
Serial plates commonly run 80x40mm or 100x60mm, thin enough for panel mounting at 0.3-1mm. Larger formats up to 200x100mm work when the serial field sits next to other spec data. Custom sizes follow your drawing.
Fit & applications
- Sequential asset numbering across a production batch
- QR or barcode fields linked to a maintenance database
- Serialized rating plates required for audit or warranty records
- Model plates combining fixed text with a unique running number
Typical applications
| Industry / setting | How this product is used |
|---|---|
| Industrial pumps and compressors | Riveted serial-number plates mounted on the housing exterior track the unit through warranty claims and service records. |
| Fleet trailers and generators | Serial plates fastened near the chassis data point let technicians log the unit into maintenance and asset-tracking systems. |
| Construction and lifting equipment | Serial-number plates on crane and hoist frames get cross-referenced against load-rating certificates during inspections. |
| HVAC rooftop units | Serial plates mounted inside the access panel are matched against installation records when technicians pull replacement parts. |
| Refurbished machinery | Re-applied serial plates preserve the original unit number when equipment changes ownership or gets rebuilt. |
Specifications
| Material | 304 stainless (other grades on request) |
| Thickness | 0.3-3 mm |
| Size | 80x40mm, 100x60mm, 120x80mm, 150x100mm (custom to your drawing) |
| Marking | chemical etching |
| Surface finish | anodized (5-25 micron; hard 25-70 micron), brushed (Ra 0.4-1.2 micron), matte, mirror, plated, painted |
| Mounting | 3M/VHB adhesive (0.5-1.1mm), mounting holes, rivets, screws |
| Tolerance | +/-0.05-0.10 mm |
| MOQ | 100-500 pcs (by complexity) |
| Lead time | sample 5-7 days; bulk 12-30 days (by quantity) |
Size & price reference
| Example spec | Ref US$/pc |
|---|---|
| 304 stainless, 25 x 28 mm, 0.2 mm, simple finish | US$0.24-0.32 |
| 304 stainless, medium size, standard finish | US$0.31-0.41 |
| 304 stainless, large or specialty finish | US$0.38-0.55 |
Indicative only. Final price depends on surface finish, mounting method, marking complexity, and order quantity. Send your drawing for a factory-direct quote.
How to order
Send your sequence file or numbering rule along with the plate drawing. Himgo reviews the data format before confirming the production route.
