Aluminum Nameplates with Holes
Aluminum nameplates with punched or drilled holes, positioned to +/-0.10mm against your drawing for a reliable bolt-up fit.
Description
Screws and rivets hold a plate through vibration and repeated handling better than adhesive alone. Getting the hole positions right the first time avoids a plate that doesn’t line up on install. Himgo checks hole spacing and diameter against your drawing before cutting. A drawing with exact hole coordinates avoids a second round of samples.
Metals & surface options
Aluminum 5052/6061 in an anodized or brushed finish. Holes are punched or drilled to +/-0.10mm tolerance. Edge distance from each hole is checked so the plate doesn’t crack under load.
Typical projects
- Bolted plates on machine frames and panels
- Rivet-mounted plates on outdoor gear
- Multi-hole plates for irregular mounting patterns
- Replacement plates matching an existing hole layout
- Plates with countersunk holes for a flush, low-profile mount
Sizes we run
80x40mm to 200x100mm, thickness 0.3-3mm depending on the fastener load. Larger plates typically carry more holes to spread the load evenly.
Typical applications
| Industry / setting | How this product is used |
|---|---|
| Industrial gearbox manufacturers | Screwed through pre-drilled holes to the gearbox housing for a tamper-resistant mount |
| Playground and outdoor equipment makers | Riveted through pre-drilled holes to swing-set and slide frames for a weather-secure mount |
| Electrical enclosure OEMs | Screwed to the panel door alongside conduit knockouts using the pre-set hole pattern |
| Agricultural implement manufacturers | Bolted through pre-drilled holes to trailer and implement frames exposed to constant vibration |
Specifications
| Material | aluminum (other grades on request) |
| Thickness | 0.3-3 mm |
| Size | 80x40mm, 100x60mm, 120x80mm, 150x100mm (custom to your drawing) |
| Marking | chemical etching |
| Surface finish | anodized (5-25 micron; hard 25-70 micron), brushed (Ra 0.4-1.2 micron), matte, mirror, plated, painted |
| Mounting | 3M/VHB adhesive (0.5-1.1mm), mounting holes, rivets, screws |
| Tolerance | +/-0.05-0.10 mm |
| MOQ | 100-500 pcs (by complexity) |
| Lead time | sample 5-7 days; bulk 12-30 days (by quantity) |
Size & price reference
| Example spec | Ref US$/pc |
|---|---|
| aluminum, 25 x 28 mm, 0.2 mm, simple finish | US$0.17-0.23 |
| aluminum, medium size, standard finish | US$0.22-0.29 |
| aluminum, large or specialty finish | US$0.27-0.39 |
Indicative only. Final price depends on surface finish, mounting method, marking complexity, and order quantity. Send your drawing for a factory-direct quote.
What to send
Send a drawing with hole diameter, spacing, and edge distance. Get a quote from the factory.
