Stainless Steel Nameplates with Holes
Stainless steel nameplates with punched or drilled mounting holes, positioned to your drawing for screw, rivet, or bolt fixing.
Description
Adhesive backing isn’t always the right call, especially on hot, oily, or textured surfaces. Stainless steel nameplates with punched or drilled holes mount with screws, rivets, or bolts instead. This fixing outlasts adhesive in demanding spots. Himgo positions each hole from your drawing so it lines up with existing mounting points.
Sizes & thickness
Plates run 80x40mm to 200x100mm, thickness 0.3-5mm depending on the fastener load. Hole diameter and spacing are set to your drawing, not a fixed template.
Metals and finishes
304 or 316 stainless both punch and drill cleanly. Etching, engraving, or printing add the mark before or after hole placement. The order depends on finish and tolerance needed around each hole.
Where buyers use it
- Hot or oily equipment surfaces where adhesive fails over time
- Textured or curved housings unsuitable for adhesive backing
- Plates needing removal for service without leaving adhesive residue
- Heavy plates where screws or rivets carry more load than tape
Typical applications
| Industry / setting | How this product is used |
|---|---|
| Utility poles and junction boxes | Pre-drilled stainless plates screw directly onto outdoor enclosures without adhesive, staying fastened through temperature swings. |
| Playground and park equipment | Pre-drilled plates bolt to metal structures where adhesive-mounted labels would fail outdoors. |
| Loading dock and warehouse equipment | Pre-drilled plates screw onto dock levelers and lift equipment where vibration would loosen adhesive labels. |
| Agricultural machinery | Pre-drilled plates riveted to tractor and implement frames hold up to dust, vibration, and pressure-washing. |
Specifications
| Material | stainless steel (other grades on request) |
| Thickness | 0.3-3 mm |
| Size | 80x40mm, 100x60mm, 120x80mm, 150x100mm (custom to your drawing) |
| Marking | chemical etching |
| Surface finish | anodized (5-25 micron; hard 25-70 micron), brushed (Ra 0.4-1.2 micron), matte, mirror, plated, painted |
| Mounting | 3M/VHB adhesive (0.5-1.1mm), mounting holes, rivets, screws |
| Tolerance | +/-0.05-0.10 mm |
| MOQ | 100-500 pcs (by complexity) |
| Lead time | sample 5-7 days; bulk 12-30 days (by quantity) |
Size & price reference
| Example spec | Ref US$/pc |
|---|---|
| stainless steel, 25 x 28 mm, 0.2 mm, simple finish | US$0.24-0.32 |
| stainless steel, medium size, standard finish | US$0.31-0.41 |
| stainless steel, large or specialty finish | US$0.38-0.55 |
Indicative only. Final price depends on surface finish, mounting method, marking complexity, and order quantity. Send your drawing for a factory-direct quote.
Start a quote
Send your drawing for a factory-direct quote, marking hole position, diameter, and fastener type. Himgo confirms hole tolerance before production begins.
