Custom Grille Car Emblems
Grille emblems carry more mechanical stress than other placements, so mounting-point strength gets reviewed before the finish.
Description
A grille emblem takes more mechanical stress than a rear or side badge – vibration, washing, occasional stone impact. Himgo reviews the mounting studs or screw points against the grille material before confirming wall thickness. Mount strength gets checked first here, before the finish is set.
Where it fits
- Front grille brand-logo emblems
- Bumper-mounted badges needing rigid mounting
- Truck and SUV grille badges
- Motorcycle front-fascia emblems
- Badges set into a cut grille opening
Common sizes
Grille badges sit at the larger end of the range, 80mm to 100mm, with thickness 3-5mm to hold rigidity through the mounting studs. Tolerance is held to +/-0.10-0.20mm so the badge seats flush in the opening.
Materials & finishes
Zinc-alloy die casting gives the wall strength (0.8-1.2mm) this position needs; stainless steel is an option where a grille sees road salt or wash chemicals. Chrome or nickel plating runs 5-25 micron; painted finishes suit two-tone grilles.
Typical applications
| Industry / setting | How this product is used |
|---|---|
| Passenger car front-end assembly | Center badge fixed to the grille bar, aligned with the hood centerline. |
| Pickup truck grille programs | Brand emblem mounted to the grille shell above the bumper. |
| Off-road/4×4 conversion shops | Grille insert emblem swapped in to replace the factory badge on a lifted build. |
| Motorcycle fairing manufacturers | Small grille-style vent badge fitted to the front fairing panel. |
| Classic car grille restoration | Reproduction grille emblem sized to match the original mounting holes. |
Specifications
| Material | zinc die-cast (other grades on request) |
| Thickness | 2-5 mm |
| Size | 40mm, 60mm, 80mm, 100mm (custom to your drawing) |
| Marking | zinc die casting, metal stamping, electroforming, plating |
| Surface finish | chrome/gold/nickel plating (5-25 micron), painted, PVD (gun-black, gold, rose gold, matte black) |
| Mounting | 3M adhesive, pins, screws, studs |
| Tolerance | +/-0.10-0.20 mm (die-cast) |
| MOQ | 100-500 pcs (by complexity) |
| Lead time | sample 5-7 days; bulk 12-30 days (by quantity) |
| Tooling | US$150-2,000 one-time (by complexity) |
Size & price reference
| Example spec | Ref US$/pc |
|---|---|
| zinc die-cast, 50 mm, 2.5 mm, simple finish | US$0.45-0.92 |
| zinc die-cast, medium size, standard finish | US$0.85-1.40 |
| zinc die-cast, large or specialty finish | US$1.26-2.07 |
Indicative only. Final price depends on surface finish, mounting method, marking complexity, and order quantity. Send your drawing for a factory-direct quote.
Getting a quote
Grille cut-out dimensions and mounting-point spacing come first – send them with the artwork. Stud or screw placement gets confirmed before sampling. Get a quote from the factory.
