Heavy Duty Stainless Steel Asset Tags
Heavier-gauge stainless tags built to hold up under frequent handling on machinery and material-handling equipment.
Description
Some equipment tags get scraped by tools, forklifts, or repeated handling. Stainless steel holds up under that kind of contact better than a thinner aluminum tag. A heavier gauge also resists bending when a tag sits on a load-bearing surface.
Metals & surface options
304 or 316 stainless in 0.3-1.5mm gauge gives the extra body this duty calls for. Brushed finish hides handling marks better than a mirror polish would. Himgo checks grade and gauge against how the equipment gets handled day to day.
Typical projects
- Heavy machinery and press equipment
- Forklift and material-handling gear
- Load-bearing structural components
- Equipment moved or handled frequently
Sizes we run
50x20mm and 75x25mm are common for equipment-facing tags. 30mm round fits compact housings. Thickness runs toward the upper end of the 0.3-1.5mm range for this duty. Larger or heavier tags can be sized to your drawing.
Typical applications
| Industry / setting | How this product is used |
|---|---|
| Chemical processing plants | Fixed to tanks and pipe-mounted equipment where the stainless tag resists exposure to corrosive vapors. |
| Marine vessel engine rooms | Mounted on shipboard machinery, holding up against constant saltwater humidity below deck. |
| Oil and gas field equipment | Fixed to wellhead and pumping equipment exposed to weather, dust, and abrasive handling. |
| Food and beverage processing lines | Riveted to stainless machine frames rated for daily steam cleaning and sanitizing. |
| Mining and quarry equipment | Mounted on heavy equipment where the tag stays legible under dust, impact, and rough handling. |
Specifications
| Material | stainless steel (other grades on request) |
| Thickness | 0.3-1.5 mm |
| Size | 25x25mm, 40x15mm, 50x20mm, 75x25mm (custom to your drawing) |
| Marking | laser engraving for variable data |
| Surface finish | colored or natural anodized, brushed, matte |
| Mounting | 3M/VHB adhesive, mounting holes, rivets |
| Tolerance | +/-0.05-0.10 mm |
| Variable data | serial numbers, QR codes, or barcodes |
| MOQ | 100-500 pcs (by complexity) |
| Lead time | sample 5-7 days; bulk 12-30 days (by quantity) |
Size & price reference
| Example spec | Ref US$/pc |
|---|---|
| stainless steel, 25 x 50 mm, 0.5 mm, simple finish | US$0.21-0.36 |
| stainless steel, medium size, standard finish | US$0.34-0.51 |
| stainless steel, large or specialty finish | US$0.47-0.74 |
Indicative only. Final price depends on surface finish, mounting method, marking complexity, and order quantity. Send your drawing for a factory-direct quote.
What to send
Send the equipment type and handling conditions along with your preferred size. Get a quote from the factory.
