Equipment Adhesive Metal Labels
An adhesive-mounted label for equipment housings, built for a model or serial field without drilling into the finished surface.
Description
Machine builders often need a label on a housing that can’t be drilled after painting. This adhesive format solves that, sitting flat on the enclosure with no fasteners. That keeps the paint seal and any coating underneath intact.
Applications
This format is built for equipment surfaces that can’t take a hole:
- Control panels and enclosure doors
- Machine housings with a model or serial field
- Warning text next to a brand mark
- Spec labels on painted equipment covers
Material and finish choices
Aluminum and stainless steel are the common bases, in brushed or matte finish. Etching or laser marking adds fixed text; printing handles color branding. Laser marking is the usual pick once a model or serial field changes by unit.
Standard size guide
Sizes run from 40x20mm up to 80x25mm, in 0.2-1mm stock with a thin 3M backing. Larger or custom shapes are cut to your drawing.
Typical applications
| Industry / setting | How this product is used |
|---|---|
| Industrial machine builders | Adhesive spec label applied to control panel doors listing voltage, model, and rating data |
| HVAC equipment manufacturers | Adhesive nameplate applied to air handler unit exteriors carrying model and serial data |
| Material handling equipment makers | Label applied to forklift and conveyor frames carrying capacity and model data |
| Laboratory instrument manufacturers | Equipment ID label applied to benchtop device housings for asset tracking |
| Generator and pump manufacturers | Adhesive label applied to housing exteriors carrying spec data for field technicians |
Specifications
| Material | aluminum (other grades on request) |
| Thickness | 0.2-1 mm |
| Size | 40x20mm, 60x30mm, 80x25mm, 30x30mm (custom to your drawing) |
| Marking | chemical etching, screen/UV printing, brushing, laser marking |
| Surface finish | brushed, anodized, printed color, matte |
| Mounting | thin 3M adhesive backing, mounting holes |
| Tolerance | +/-0.05-0.10 mm |
| MOQ | 100-500 pcs (by complexity) |
| Lead time | sample 5-7 days; bulk 12-30 days (by quantity) |
Size & price reference
| Example spec | Ref US$/pc |
|---|---|
| aluminum, 40 x 20 mm, 0.3 mm, simple finish | US$0.10-0.19 |
| aluminum, medium size, standard finish | US$0.17-0.27 |
| aluminum, large or specialty finish | US$0.25-0.40 |
Indicative only. Final price depends on surface finish, mounting method, marking complexity, and order quantity. Send your drawing for a factory-direct quote.
Send for quote
Send the drawing, the data fields you need, and the mounting surface. Himgo confirms adhesive type before sampling. Send your drawing for a factory-direct quote.
