Stainless Steel Tags with Holes
Stainless tags punched to your exact hole size, count, and spacing. Matched to the screw, rivet, or wire already in use.
Description
The hole is often the part of a tag that gets overlooked. It gets noticed only once it’s the wrong size for the screw or wire on hand. Getting diameter, count, and position right matters as much as the material, especially where a tag must sit flush and stay still.
Applications
- Tags screwed directly to an equipment face
- Tags riveted through a panel or bracket
- Tags wired through a single hole onto a valve or pipe
- Tags bolted in pairs where rotation must be prevented
- Tags matched to existing bolt patterns on a frame
Material and finish choices
Stainless 304 or 316 is punched with a brushed or natural finish. Hole diameter, count, and edge distance follow your drawing, matched to the fastener already in use.
Standard size guide
40x20mm typically takes a single corner hole. 75x20mm can carry two holes for a fixed, non-rotating mount. A 35mm round often uses one center hole.
Typical applications
| Industry / setting | How this product is used |
|---|---|
| Control panel enclosures | Tag screwed to the enclosure door face identifying panel number and voltage for electricians. |
| Machine guarding | Tag bolted to guard panels around moving machinery showing lockout points and hazard warnings. |
| Junction boxes | Tag screwed onto outdoor junction box lids identifying circuit and feed source. |
| Transformer yards | Tag bolted to transformer housings carrying unit number and rating for utility crews. |
Specifications
| Material | stainless steel (other grades on request) |
| Thickness | 0.5-2 mm |
| Size | 40x20mm, 50x25mm, 75x20mm, 35mm round (custom to your drawing) |
| Marking | laser engraving, metal stamping, chemical etching |
| Surface finish | brushed, matte, natural metal |
| Mounting | mounting holes, cable tie, chain, rivet |
| Tolerance | +/-0.05-0.10 mm |
| Variable data | serial numbers, QR codes, or barcodes |
| MOQ | 100-500 pcs (by complexity) |
| Lead time | sample 5-7 days; bulk 12-30 days (by quantity) |
Size & price reference
| Example spec | Ref US$/pc |
|---|---|
| stainless steel, 40 x 20 mm, 1.0 mm, simple finish | US$0.20-0.32 |
| stainless steel, medium size, standard finish | US$0.31-0.45 |
| stainless steel, large or specialty finish | US$0.41-0.63 |
Indicative only. Final price depends on surface finish, mounting method, marking complexity, and order quantity. Send your drawing for a factory-direct quote.
Send for quote
Send your fastener size and hole layout. Himgo punches to that spec and quotes direct from the factory.
