Stainless Steel Industrial Labels
A 304 or 316 stainless label built for wash-down, outdoor, or chemical-area equipment. Brushed or matte finish depending on nearby glare.
Description
304 and 316 stainless resist rust in wash-down and outdoor settings where aluminum can pit over time. Himgo builds industrial labels from either grade, etched or printed. The equipment data survives the environment it works in.
Where it fits
- Food and beverage equipment exposed to wash-down
- Marine deck hardware and outdoor utility cabinets
- Chemical-area equipment where corrosion is a concern
- Outdoor control panels facing weather exposure
Common sizes
40x20mm and 60x30mm cover most single-field labels. 80x25mm fits a model line plus a spec note. 30x30mm suits a compact code field. Any size cuts to your drawing.
Materials & finishes
Stainless 304 handles general industrial exposure; 316 steps up for higher chloride environments like coastal sites or chemical processing. Brushed finish is the standard look; matte cuts glare on nearby readouts. Etching or printing carries the equipment data.
Typical applications
| Industry / setting | How this product is used |
|---|---|
| Food and beverage plants | Washdown-area nameplate riveted to stainless machine frames that see daily caustic wash cycles. |
| Marine equipment builders | Label mounted on deck machinery housings exposed to salt spray and coastal humidity. |
| Chemical processing plants | Plate fixed to pump and reactor housings where fumes and occasional splash would corrode painted steel. |
| Pharmaceutical cleanroom lines | Nameplate mounted on stainless enclosure walls inside rooms cleaned by repeated wash-down cycles. |
| Water treatment facilities | Label riveted to pump skids and filtration units standing in continuously damp, chlorinated air. |
Specifications
| Material | stainless steel (other grades on request) |
| Thickness | 0.2-1 mm |
| Size | 40x20mm, 60x30mm, 80x25mm, 30x30mm (custom to your drawing) |
| Marking | chemical etching, screen/UV printing, brushing, laser marking |
| Surface finish | brushed, anodized, printed color, matte |
| Mounting | thin 3M adhesive backing, mounting holes |
| Tolerance | +/-0.05-0.10 mm |
| MOQ | 100-500 pcs (by complexity) |
| Lead time | sample 5-7 days; bulk 12-30 days (by quantity) |
Size & price reference
| Example spec | Ref US$/pc |
|---|---|
| stainless steel, 40 x 20 mm, 0.3 mm, simple finish | US$0.14-0.27 |
| stainless steel, medium size, standard finish | US$0.25-0.39 |
| stainless steel, large or specialty finish | US$0.36-0.57 |
Indicative only. Final price depends on surface finish, mounting method, marking complexity, and order quantity. Send your drawing for a factory-direct quote.
Getting a quote
Send the exposure condition and the data fields you need. Himgo confirms 304 or 316 and the finish before sampling. Request a sample before bulk production.
