Heat Resistant Metal Labels
Material and mounting reviewed against how close the label sits to a heat source. Stainless or aluminum, adhesive or holes, picked case by case.
Description
Does the label sit near a heat source, or just in a warm room? That answer decides the material and the adhesive. Himgo reviews the operating condition before confirming stainless or aluminum, holes or adhesive, for a heat-area label.
Build options
Stainless 304 or 316 covers surfaces that run hotter, since it holds finish and edge better than aluminum at higher temperatures. Aluminum stays the choice where the mounting point runs cooler. Mounting holes are recommended once surface temperature climbs; thin 3M adhesive backing is reviewed case by case for moderate warmth.
Common dimensions
40x20mm and 60x30mm are the common footprints for a heat-area label. Thickness runs 0.2-1mm depending on whether the label mounts by adhesive or by holes. Any size cuts to your drawing.
Fit & applications
- Labels near motor housings and drive units
- Oven and dryer equipment ID plates
- Exhaust-run and duct labels
- Heat-treat line equipment tags
Typical applications
| Industry / setting | How this product is used |
|---|---|
| Foundries | Label riveted to the furnace housing where surface temperatures exceed what adhesive or printed tags can survive. |
| Industrial oven manufacturers | Nameplate mounted on the oven’s outer shell near the heating chamber, staying legible through repeated heat cycling. |
| Boiler room installers | Plate fixed to the boiler jacket identifying model and capacity in an area too hot for standard labels. |
| Kiln builders (ceramics and brick) | Label mounted on the kiln exterior wall carrying model data despite ongoing radiant heat exposure. |
| Exhaust and flue system fabricators | Tag riveted near the flue outlet identifying duct run and rating in a sustained high-heat zone. |
Specifications
| Material | aluminum (other grades on request) |
| Thickness | 0.2-1 mm |
| Size | 40x20mm, 60x30mm, 80x25mm, 30x30mm (custom to your drawing) |
| Marking | chemical etching, screen/UV printing, brushing, laser marking |
| Surface finish | brushed, anodized, printed color, matte |
| Mounting | thin 3M adhesive backing, mounting holes |
| Tolerance | +/-0.05-0.10 mm |
| MOQ | 100-500 pcs (by complexity) |
| Lead time | sample 5-7 days; bulk 12-30 days (by quantity) |
Size & price reference
| Example spec | Ref US$/pc |
|---|---|
| aluminum, 40 x 20 mm, 0.3 mm, simple finish | US$0.10-0.19 |
| aluminum, medium size, standard finish | US$0.17-0.27 |
| aluminum, large or specialty finish | US$0.25-0.40 |
Indicative only. Final price depends on surface finish, mounting method, marking complexity, and order quantity. Send your drawing for a factory-direct quote.
How to order
Send the surface temperature range and the mounting surface. Himgo confirms material and fixing before sampling, since a label that lifts is worse than no label at all. Send your drawing for a factory-direct quote.
