Equipment Serial Number Labels
A laser-marked serial tag for tracking production one unit at a time. Aluminum or stainless base, sequential or list-based data.
Description
Laser marking writes variable data straight into the metal. A production run can be numbered one unit at a time without new tooling. Himgo runs serial number labels this way, for equipment that needs individual tracking.
Build options
Aluminum or stainless serves as the base metal, depending on the equipment’s exposure. Laser marking cuts the serial line into the surface, so it stays legible through handling. Matte or anodized finish keeps the numbers easy to read against the background.
Common dimensions
40x20mm suits a serial-only tag. 60x30mm adds room for a barcode or QR code beside the number. Any size cuts to your drawing.
Fit & applications
- Production serial tracking on finished units
- Warranty registration tags
- Equipment audit-trail labels
- Asset tags matched to a serial database
Typical applications
| Industry / setting | How this product is used |
|---|---|
| Equipment rental fleets | Serial tag riveted to the machine frame used to track individual units across rental locations. |
| Laboratory instrument manufacturers | Label mounted on the instrument housing carrying a serial number referenced in calibration records. |
| Outdoor power equipment makers | Plate fixed to the mower or generator frame carrying a serial number used for warranty and theft recovery. |
| Pressure equipment fabricators | Nameplate riveted near the vessel access point carrying serial data referenced during inspection visits. |
| Industrial scale and instrument makers | Label mounted on the housing base carrying a serial number tied to the unit’s calibration certificate. |
Specifications
| Material | aluminum (other grades on request) |
| Thickness | 0.2-1 mm |
| Size | 40x20mm, 60x30mm, 80x25mm, 30x30mm (custom to your drawing) |
| Marking | chemical etching, screen/UV printing, brushing, laser marking |
| Surface finish | brushed, anodized, printed color, matte |
| Mounting | thin 3M adhesive backing, mounting holes |
| Tolerance | +/-0.05-0.10 mm |
| MOQ | 100-500 pcs (by complexity) |
| Lead time | sample 5-7 days; bulk 12-30 days (by quantity) |
Size & price reference
| Example spec | Ref US$/pc |
|---|---|
| aluminum, 40 x 20 mm, 0.3 mm, simple finish | US$0.10-0.19 |
| aluminum, medium size, standard finish | US$0.17-0.27 |
| aluminum, large or specialty finish | US$0.25-0.40 |
Indicative only. Final price depends on surface finish, mounting method, marking complexity, and order quantity. Send your drawing for a factory-direct quote.
How to order
Send the serial data, sequential or from a list, along with the mounting method. Himgo confirms the marking process before sampling. Request a sample before bulk production.
