316 Stainless Steel Nameplates
316 stainless steel nameplates for coastal, washdown, or chemical-plant equipment where 304 wears faster than expected.
Description
Coastal air, cleaning chemicals, and washdown wear through 304 steel fast. Plants often see this happen sooner than planned. 316 stainless adds molybdenum to the mix. That gives it more resistance in salty or harsh settings. Himgo uses 316 for nameplates that stay exposed long-term.
Build options
316 uses the same etching, laser, and print steps as 304. Thickness stays the same too: 0.3-5mm. It fits sites with the highest corrosion risk. Marine, coastal, and chemical-plant sites are common cases.
Common dimensions
Sizes match the standard range for nameplates: 80x40mm to 200x100mm, at 0.3-5mm thick. Bigger plates and custom cutouts follow your drawing.
Fit & applications
- Marine and coastal gear with steady salt exposure.
- Food, drink, and pharma washdown areas.
- Chemical-plant machines exposed to harsh agents.
- Any 304 part wearing out faster than planned.
Typical applications
| Industry / setting | How this product is used |
|---|---|
| Marine deck and hull equipment | 316 nameplates resist the continuous saltwater spray and salt-air corrosion that pits lower-grade stainless. |
| Coastal desalination and water treatment plants | 316 plates on pumps and piping hold up to high-chloride process water. |
| Chemical processing plants | 316 data plates on reactors and piping resist the acidic and caustic washdown common in these environments. |
| Offshore oil and gas platforms | 316 plates on deck equipment resist salt spray and sour-gas atmospheres. |
Specifications
| Material | 316 stainless (other grades on request) |
| Thickness | 0.3-3 mm |
| Size | 80x40mm, 100x60mm, 120x80mm, 150x100mm (custom to your drawing) |
| Marking | chemical etching |
| Surface finish | anodized (5-25 micron; hard 25-70 micron), brushed (Ra 0.4-1.2 micron), matte, mirror, plated, painted |
| Mounting | 3M/VHB adhesive (0.5-1.1mm), mounting holes, rivets, screws |
| Tolerance | +/-0.05-0.10 mm |
| MOQ | 100-500 pcs (by complexity) |
| Lead time | sample 5-7 days; bulk 12-30 days (by quantity) |
Size & price reference
| Example spec | Ref US$/pc |
|---|---|
| 316 stainless, 25 x 28 mm, 0.2 mm, simple finish | US$0.26-0.36 |
| 316 stainless, medium size, standard finish | US$0.34-0.45 |
| 316 stainless, large or specialty finish | US$0.42-0.61 |
Indicative only. Final price depends on surface finish, mounting method, marking complexity, and order quantity. Send your drawing for a factory-direct quote.
How to order
Send your drawing for a factory-direct quote. Note the site conditions too. That helps Himgo confirm 316 is the right call. A sample is ready for review before bulk runs.
